034 Motorsport - Audi B9 Q5 2.0 TFSI Tuning - ECU & TCU Tuning Bundle

Thermal Management Safety Strategies:

With increased power, comes increased heat. With increased heat, comes the need for additional management. For charge air temperature, 034Motorsport has implemented key safety features to keep your engine running optimally and safely in virtually any condition - just like the OEM calibration. Substantial effort was spent on balancing the trade off of charge temp for power, and improving the compressor efficiency so that it doesn't generate too much charge temp.

Charge Air Temp: When the charge temp exceeds 80*C there is a reduction in power output. When the charge temp exceeds 85*C there is a more significant reduction in power output. This charge temp limitation is there to prevent knock events, which can severely damage a motor. With these safety measures in place, you can confidently drive your car, from the top of Pikes Peak to Death Valley, knowing the factory ECU has optimal performance and safety covered..

Coolant Temp/Fan Strategy: From the factory, Volkswagen likes to run hotter water temps to reduce fluid friction losses from cooler, more viscous oil. While better for efficiency, this strategy becomes a safety issue when loads and heat are increased. 034Motorsport calibrators have rescaled the coolant temperature targets and fan control strategies to target lower coolant temperatures when in higher heat conditions, allowing the car to run within a safe heat range rescaled for the added heat that comes from tuning the engine. Once again, this means that 034Motorsport calibrators have kept your confidence in safety fully intact from the OEM configuration.

Start/Stop Button Memory:

Dynamic+ Tuning for the EA888.3 2.0T retains the Start/Stop engine functionality, but allows users to set the memory for the system based on preference. If you do not want the Start/Stop system to run, turn it off via the in-cabin button and the car will store that selection even after key cycling the car. If you would like it to stay on, select it to be on via the in-cabin button. This is done in a completely OEM fashion, helping enhance the overall experience of driving your car!

Free Revving in Neutral and Park

The rev-limiter is now removed while in Neutral and Park. Impress friends and annoy those around you with limitless ease!

Accurate Boost Reporting

For vehicles equipped with the digital boost gauge, your vehicle will now accurately scale boost levels!

Optimized DSG Equipped Vehicles!

034Motorsport calibrators spent equal time refining the ECU calibrations on DL382 G1 & G2 transmission equipped for optimized performance and smooth drivability without compromising the reliability and safety of your engine and transmission.

Dynamic+ TCU Features:

DL382 TCU tune

Torque Safety Strategy Enhancements: The Dynamic+ ECU Tuning accurately reports torque values to the TCU to ensure that all safety systems are intact in both control units, and the added torque from tuning is properly adjusted for when driving/shifting, including all safety systems designed to protect the engine and transmission. This results in better shift quality as the transmission is not having to reduce engine torque or having to adapt to misreported inputs.

Clutch Pressure Increases: In order to safely apply the increased horsepower and torque, DSG Clutch Pressures are increased in all drive modes. Expect to feel firmer and more solid shifts!

Optimized Shift Points: In order to take advantage of the increased powerband from the turbocharger, Dynamic+ Tuning optimizes the shift points in Drive & Sport Mode to maximize acceleration while retaining smooth drivability.

Improved Shift Speeds: To further enhance the acceleration of your Audi, the DL382 shift times are dramatically decreased in all driving modes, which ultimately results in quicker acceleration.

Launch Control Optimizations: From the factory, the DL382 launch control strategies used are very neutered and designed for a vehicle on a non-optimal surface with low-grip tires. 034Motorsport Engineers have optimized the launch by raising the factory RPM stall to take advantage of a better surface and a grippier tire. This ensures that your vehicle will 60ft much more effectively and efficiently, bringing down your 0-60 and 1/4mi times!

Kickdown Switch Disabled in Manual Mode: When in Manual mode, you no longer need to worry about accidentally pushing through the kickdown switch on the throttle pedal!

Gear Display in Instrument Cluster: From the factory, the instrument cluster only displayed "D" or "S" when in Drive or Sport. Now, your instrument cluster will let you know what transmission mode you are in, as well as the gear!

034 MOTORSPORT DYNAMIC+ END USER FLASHING KIT

034Motorsport's Dynamic+ End User Flashing Kit allows customers to install their 034Motorsport Dynamic+ Performance Software themselves. In addition, End User Flashing allows Dynamic+ Performance Software customers to receive and install software updates and revisions, flash back to stock, or upgrade to the next stage of performance software for their vehicle.

Requirements for End User Flashing:

• Windows 7 or Windows 10/11 Laptop with Available USB Port
• Power Supply for Laptop
• Secure Wired (Or Very Stable WiFi) High-Speed Internet Connection
• CTEK Trickle Charger (Or Similar)
• Available Electrical Outlets

034Motorsport End User Flashing Kit Contents:

• 034Motorsport OBD-II Adapter
• USB-A to USB-B Cable
• Carrying Case
• User Credentials (Provided Via Email)

How to use the end user flash cable & software

• Receive welcome email (after purchase) with 034 software account and user guide
• Plug into OBD2 port and USB port on laptop & take read of stock ECU / TCU
• Send 034 stock file details from software (very easy)
• Plug back into OB2 port & USB and flash tune your ECU / TCU

Once you have taken the stock read of the ECU you can always flash your car back to stock at any time. You can also flash between stages.

The reading / flashing and software process is not complicated. Everything is straight forward and anyone who has the computer skills to send an email can do this process.

Initial read time - 10 minutes
First flash time - 20 minutes
Flash back to stock - 10 minutes
Upgrading files (stage 1 to 2) - 5 minutes
Flashing between files and stages - 5 minutes

Download: 034 Motorsport Dynamic + user manual

What happens next?

• We will create a tuning order for you with head office
• We will post you the Dynamic+ tuning cable - Express post only
• Please wait and 034 tuning support will send you an account activation email. This contains instructions and links to download the tuning software
• A user manual is available to download from every tuning product page
• You then proceed to take a read of your ECU/TCU and flash tune your vehicle
• 034 will provide direct support for you. You will be able to communicate with the software engineers
• Enjoy the transformation of your vehicle
